Arducam B0020 5 Mega pixel Camera Module OV5642 1080P JPEG Output

Features:

• Onboard LDO regulators for 2.8V and 1.8V
• Single 3.3V power input
• 2.54mm (0.1 inch) standard pin out
• Open source project www.ArduCAM.com supported
• active array size: 2592 x 1944
• power supply:
• core: 1.5VDC + 5% (internal regulator)
• analog: 2.6 ~ 3.0V
• I/O: 1.7 ~ 3.0V
• output formats :
• (8-bit): YUV(422/420) / YCbCr422,
• RGB565/555/444, CCIR656,
• 8-bit compression data,
• 8/10-bit raw RGB data
• lens size: 1/4"
• input clock frequency: 6 ~ 27 MHz
• shutter: rolling shutter
• maximum image transfer rate:
• 5 megapixel (2592×1944): 15 fps (and any size scaling down from 5 megapixel)
• 1080p (1920×1080): 30 fps
• 720p (1280×720): 60 fps
• VGA (640×480): 60 fps
• QVGA (320×240): 120 fps
• scan mode: progressive
• pixel size: 1.4 µm x 1.4 µm
• image area: 3673.6 µm x 2738.4 µm
• RAW,RGB,YUV,JPEG output support
• External 1/4 inch high quality M12x0.5 lens
• Lens Specification: sensor size: 1/2.7"; EFL:4mm; F/N:1.8; BFL:6.68mm; HFOV: 56 degree (SKU: U1462)

  Note: If you would like to change the lens, please choose the lens from the M12 lens kit here:

  SKU: LK001 Arducam M12 mount camera lens kit for Arduino and Raspberry Pi camera

  SKU: LK002 Arducam Low Distortion M12 mount camera lens kit for Arduino and Raspberry Pi camera

Applications:

Additional Resources:

• User Guide – Arducam 5MP OV5642 Camera Module
• Sensor Datasheet – OmniVision OV5642
• Arducam Documentation – Arducam Camera Breakout Boards
• Lens Options – Arducam M12 Mount Lens Kit, Arducam Low Distortion M12 Mount Lens Kit
