Arducam B0224 OV9281 1MP Global Shutter NoIR Mono Camera Module with 130deg M12 Mount for Raspberry Pi

Arducam B0224 OV9281 1MP Global Shutter NoIR Mono Camera Module with 130deg M12 Mount for Raspberry Pi

Artnr.: AC2-202240
GTIN: \000026B0224
Hersteller: Arducam

Arducam OV9281 1MP Global Shutter NoIR Mono Camera Module with 130deg M12 Mount for Raspberry Pi

49,90 €

inkl. 19% MwSt.

(41,93 € exkl. MwSt.)

zzgl.

ab Lager lieferbar (knapper Bestand)

Beschreibung
Kundenrezensionen

The Arducam monochrome (B&W) global shutter 1280×800 resolution OV9281 camera module is mainly designed for Raspberry Pi boards, and it can be connected directly to RPi's CSI-2 camera interface without additional hardware.

This Arducam OV9281 global shutter camera (Rev.B) is compatible with the official V4L2 camera driver, and you can get it working easily just by enabling the overlay.

The sensor's global shutter and excellent low-light sensitivity allow it to be used for any application that needs gesture detection, head, and eye tracking, and depth and motion detection.

Note:

Only the Rev.B version supports the official V4L2 driver. Please use Arducam MIPI camera driver for the first version.
Only Bullseye system supports libcamera, using Pivariety driver. For Buster system,unicam is supported, using OBISP driver.
The official V4L2 driver only supports RAW data and manual exposure.
This camera and RPI driver doesn't support hardware JPEG/H.264 encoding.
Raspberry Pi motherboard is not included in the package.

Key Specifications:

Sensor: Monochrome global shutter OV9281
Pixel Size: 3 µm x 3 µm
Active array size: 1280 x 800
Optical Size: 1/4 inch
Focusing Range: 30mm ~ infinite
Output interface: 2-lane MIPI serial output
Output formats: RAW
Maximum image transfer rate: 1280 x 800@120fps with the Official driver/Arducam SDK.
Board Size: 40mm x 40mm
Lens FoV: 130°(D) 110 °(H) 90°(V)
IR Sensitivity: sensitive to IR, No IR filter

Application:

Security
High dynamic range imaging
Unattended surveillance
Stereo vision
Machine vision
Automation

Package Including:

1pcs Arducam OV9281 1MP Mono Global Shutter Camera Module with 130deg M12 Mount Lens
1pcs 150mm 15pin 1.0mm to 22pin 0.5mm pitch FPC cable
1pcs 80mm 22pin 0.5mm pitch FPC cable

Additional Resources:

Arducam Documentation – OV9281 1MP Global Shutter Camera for Raspberry Pi
Video –Arducam Global Shutter OV9281 MIPI Camera Demo for Raspberry Pi
Blog – Monochrome Global Shutter Cameras on Raspberry Pi
3D Drawing – OV9281 1MP Global Shutter Camera for Raspberry Pi
Lens Options – Arducam M12 Mount Lens Kit, Arducam Low Distortion M12 Mount Lens Kit
