Enhance your ABS printing experience with our innovative support material. Designed for effortless printing and hassle-free removal, this material ensures a flawless support interface every time. Fully compatible with the AMS systems, it streamlines your ABS printing process from start to finish. Say goodbye to tedious support removal and enjoy a smoother, more efficient workflow!
Product Features
- Easy Support Removal
- Superior Support Interface Quality
- AMS Compatible
Accessory Compatibility
|
Recommended |
Not Recommended |
| Build Plate |
Smooth PEI Plate, Textured PEI Plate |
/ |
| Hotend |
0.4 mm / 0.6 mm / 0.8 mm |
0.2 mm |
| Bambu Liquid Glue / Glue Stick |
Bambu Liquid Glue / Glue Stick |
/ |
Printing Tips
- Support for ABS is soluble in limonene. Please pay attention to the usage norms and safety.
- Pungent and unpleasant odors may be released during printing. Ensure your printer is enclosed and placed in a well-ventilated area.
- When layer strength is required, it is recommended to increase the flushing volume to above 800 mm3. If the flushing is not thorough, it may reduce the layer adhesion of the model at surfaces that are on the same horizontal plane as the support surface.
- By increasing the "initial layer speed," a more peelable support can be obtained. However, this will increase the risk of warping.
- Dry the filament before use for higher print quality. Drying conditions: 80℃ for 4 hours in the blast drying oven; 85 - 95 ℃ for 6 hours in the X1 Series Heatbed. Please refer to the filament drying instructions on the Bambu Lab WIKI.
- For more support-related settings, please refer to the support section on the Bambu Lab WIKI.
Model Overview
|
Support for PLA/PETG |
Support for PLA/PETG |
Support for ABS |
Support for PA/PET |
PVA |
| Color |
Nature |
White & Black |
White |
Green |
Clear |
| Nozzle Type |
All Size / Material |
All Size / Material |
0.4 / 0.6 / 0.8 mm |
0.4 / 0.6 / 0.8 Hardened Steel |
All Size / Material |
| Nozzle Temperature |
190 - 220 ℃ |
220 - 230 ℃ |
240 - 270 ℃ |
280 - 300 ℃ |
220 - 250 ℃ |
| Bed Temperature |
35 - 60 ℃ |
35 - 45 ℃ |
80 - 100 ℃ |
80 - 100 ℃ |
35 - 45 ℃ |
| Printing Speed |
< 100 mm/s |
< 200 mm/s |
< 100 mm/s |
< 100 mm/s |
< 200 mm/s |
| Solubility |
Water-insoluble |
Water-insoluble |
Water-insoluble, limonene-dissolvable |
Water-insoluble |
Water-dissolvable |
| Dry before Use |
Optional |
Optional |
Optional |
Required |
Required |
| Dry Protection during Use |
Optional |
Optional |
Optional |
Required |
Required |
| Filament Compatibility |
PLA, PETG |
PLA |
ABS |
PAHT-CF,PA6-CF,PA6-GF, PET-CF |
PLA, PETG |
| Recommended Printing Settings |
| Drying Settings (Blast Drying Oven) |
80 ℃, 8 h |
| Printing and Keeping, Container's Humidity |
<20% RH (Sealed, with Desiccant) |
| Nozzle Temperature |
240 - 270 ℃ |
| Bed Temperature (with Glue) |
80 - 100 ℃ |
| Printing Speed |
< 100 mm/s |
| Physical Properties |
| Density |
1.16 g/cm³ |
| Vicat Softening Temperature |
N/A |
| Heat Deflection Temperature |
N/A |
| Melting Temperature |
185 ℃ |
| Melt Index |
11.6 ± 0.7 g/10 min |
| Mechanical Properties |
| Tensile Strength |
N/A |
| Breaking Elongation Rate |
N/A |
| Bending Modulus |
N/A |
| Bending Strength |
N/A |
| Impact Strength |
N/A |
Extended Specifications
Package Contents
- Filament x 1 & Desiccant x 1
- Package x 1
