SDS6208L
SDS6204L
|
SDS6108L
SDS6104L
|
SDS6058L
SDS6054L
|
| Mess-Funktionen |
Mehr als 50 Parameter, unterstützt Statistiken mit Histogramm und Trend-Anzeige |
| Mathematische Funktionen |
4 Traces
8 MPts FFT, +, -, ×, ÷, d/dt, ∫dt, √, Identity, Negation, Absolute, Sign, ex, 10x, ln, lg, Interpolation, MaxHold, Average, ERES, Formeleditor |
| Datenverarbeitung |
Search&Navigate, History, Mask Test, Bode Plot, Power Analysis (optional), Counter |
| Serielle Trigger/Dekoder |
I2C, SPI, UART, CAN, LIN (Standard)
CAN FD, FlexRay, I2S, MIL-STD-1553B, SENT, Manchester (optional) |
| Logik-Analysator (optional) |
16 Kanäle, 1,25 GS/s Abtastrate, 62,5 MPts Aufzeichnungslänge pro Kanal |
| Signalgenerator (optional) |
1 Kanal, 25 MHz Bandbreite, 125 MGS/s Abtastrate, 50 KPts Speichertiefe |
| Schnittstellen |
USB 3.0 Host x2, USB 2.0 Host x2, USB 2.0 Device (USBTMC), 1000M LAN (SCPI over VXI-11, SCPI over Telnet (port:5024), SCPI over Socket (port:5025), micro SD card, External trigger, Auxiliary output (TRIG OUT,PASS / FAIL), 10 MHz In, 10 MHz Out |
| Display |
HDMI Displayanschluss (1280x800 Pixel) |
| Mitgelieferte Tastköpfe |
1x 500 MHz passive probe supplied for each channelIt can be used as a stand-alone oscilloscope by being connected to an external display and a mouse. It can also be remotely controlled over LAN thanks to the convenient built-in web server. |
