Siglent SPS5165X High-Power Benchtop Power Supply

Datasheet (EN)

Artno.: SL8-351653

Siglent SPS5165X High-Power Benchtop Power Supply

Programmable Switching DC Power Supply, 3 Channels, 3x 160V/7.5A/360W, Resolution 1mV/1mA, 2.4" OLED Display, USB / USB Host / LAN / Analog Control Interface

2,485.00 € incl. 19% VAT

2,088.24 € excl. VAT

Free shipping within Germany

Orderable

Shipping time: 5 - 7 business days

Description

The SPS5000X-Series is a programmable Switching DC Power supply series that provides a wide range of output power using single-channel and multi-channel output configurations coupled with constant power capability.

The series of power supplies includes sixteen models with voltages to 160 VDC and power to 1080 W. The SPS5000X supplies can be connected in series (2 units) or in parallel (3 units) to meet the requirements of 0~320V and 0~270A, with a maximum combined power of 3240W.

Key Features

User enabled internal output discharge circuit to accelerate the down programming of the output voltage
Remote Voltage Sensing
List function up to 50 steps; can be created from the front panel or by importing list sequence files from a USB memory device
External analog voltage and resistor control of voltage or current output
External voltage and current monitoring output
OVP, OCP, LPP, OTP protection.
4-inch OLED high brightness liquid crystal display, 170-degree viewing angle
Standard Interface: USB, LAN, Analog Control Interface
Optional Interface: USB-GPIB module
1/2, 1/3, 1/6 rack mount size
Embedded Web Server offers remote control through a web browser without the need for the driver or software

Model Overview

		SPS5161X	SPS5162X	SPS5163X	SPS5164X	SPS5165X
Output channels		1			2	3
Rated output	Voltage	150 V
Rated output	Current	7.5 A	15 A	22.5 A	7.5 A
Output Power		360 W	720 W	1080 W	720 W	1080 W
Display		2.4" OLED
Resolution	Voltage	1 mV
Resolution	Current	1 mA
Interfaces		USB Device, LAN, analog control

		SPS5161X	SPS5162X	SPS5163X	SPS5164X	SPS5165X
Program Accuracy	Voltage	± (0.1% + 100mV)
Program Accuracy	Current	± (0.1% + 5mA)	± (0.1% + 15mA)	± (0.1% + 20mA)	± (0.1% + 5mA)
Readback Accuracy	Voltage	± (0.1% + 100mV)
Readback Accuracy	Current	± (0.1% + 5mA)	± (0.1% + 15mA)	± (0.1% + 20mA)	± (0.1% + 5mA)
Ripple&Noise	CV Mode	≤12 mVrms	≤15 mVrms	≤20 mVrms	≤12 mVrms
Ripple&Noise	CC Mode	≤15 mArms	≤30 mArms	≤45 mArms	≤15 mArms
Dimensions	WxHxD	71 x 124 x 418 mm	142 x 124 x 418 mm	214 x 124 x 418 mm	142 x 124 x 418 mm	214 x 124 x 418 mm
Weight		3.3 kg	5.3 kg	7.5 kg	5.5 kg	7.8 kg
