Bambu Lab PETG-CF Filament on Spool 31100 Black
Artno.: BL5-631100
Carbon Fiber Reinforced PETG, PETG-CF Filament, Diameter 1.75mm +/- 0.03mm, Less Clumping and Stringing, Premium Print Surface, Improved Mechanical Properties and High Flexibility, AMS Compatible, RFID
Variant
38.90 € incl. 19% VAT
32.69 € excl. VAT
On stock

Shipping time: 1 - 3 business days

Description

Bambu PETG-CF is a composite material consisting of PETG and carbon fiber. The new formula greatly improves printing quality by reducing nozzle clogging and clumping compared to traditional PETG. With the addition of carbon fiber, Bambu PETG-CF offers improved strength while maintaining good toughness and a shiny appearance. It is an ideal material for drone parts, racing models, and various functional parts that require both high performance, especially impact strength, and a sleek appearance.

Printing Tips

  • Bambu PETG-CF needs proper drying before printing. Drying conditions: 65℃ for 8 hours. Store in a dry environment after use. Dry before use if the material absorbs moisture. For more details, please refer to: Filament drying instructions on Bambu Lab Wiki.
  • To achieve stronger Z-adhesion, please set a higher infill density and do not use an open-frame printer or set fan percentages too high to avoid overcooling.
  • To achieve shinier looks, set lower speeds and relatively higher temperatures.
  • Feel free to reuse your Bambu Reusable Spool. Bambu Lab has designed the entire filament feeding system around a reusable spool design and achieved at least 20% less plastic waste in filament consumption.
  • All printing parameters are embedded in RFID, which can be read through Bambu Lab AMS (Automatic Material System). Load and print! No more tedious setting steps.
  • Although PETG-CF is compatible with AMS, it's not ideal for AMS Lite.

Model Overview

Color Hex Code Display
Brick Red #9F332A
Violet Purple #583061
Indigo Blue #324585
Malachite Green #16B08E
Black #000000
Titan Gray #565656
Recommended Printing Settings
Drying Settings (Blast Drying Oven) 65 ℃, 8 h
Printing and Keeping, Container's Humidity <20% RH (Sealed, with Desiccant)
Nozzle Temperature 240 - 270 ℃
Bed Temperature (with Glue) 65 - 75 ℃
Printing Speed < 200 mm/s
Physical Properties
Density 1.25 g/cm³
Vicat Softening Temperature 85 ℃
Heat Deflection Temperature 74 ℃
Melting Temperature 225 ℃
Melt Index 19.3 ± 2.4 g/10 min
Mechanical Properties
Tensile Strength 35 ± 5 MPa
Breaking Elongation Rate 10.4 ± 0.6 %
Bending Modulus 2910 ± 260 MPa
Bending Strength 70 ± 5 MPa
Impact Strength 41.2 ± 2.6 kJ/m²

Package Contents

  • Filament x 1 & Desiccant x 1
  • Package x 1
  • Filament Label x 1

Features

Less clumping and stringing
Bambu PETG-CF is improved with a modified formula that specifically addresses the issue of clumping and sticking to nozzle during PETG printing.
Premium print surface
Carbon fiber brings advanced texture to the print surface, while retaining the shine of PETG itself.
Carbon Fiber Texture
Carbon fiber brings soft reflection, minimal layer lines and a unique delicate texture.
Shiny Finish
Different from PLA-CF's matte finish, PETG-CF offers a shiny finish and thus one more choice.
Strong XY Performance
The addition of carbon fiber also significantly enhances the XY strength of PETG without sacrificing layer bonding.
High Flexibility
The addition of carbon fiber also significantly enhances the XY strength of PETG without sacrificing layer bonding.


Shipping weight: 1.40 Kg
